Double bottoms are by machine prefabricated base plates, which are built on a sub-construction into dry construction way. Any, freely plate stored on the supports, can be taken up to the entrance to the soil cavity. For the surfaces a multiplicity of different linings is available. Thus there are plates, which are occupied with parquet or natural stone just like PVC, natural rubber, linoleum or carpet tiles. The double bottom consists in the rough of two main parts:

The mother boards, from different materials and also freely selectable upper linings in the raster 600 x 600 mm

The sub-construction, consists of galvanized steel columns of different lengths, is adjustable and locking in the height. For the carrying capacity reinforcement or reinforcement there are additionally so-called "C" of profiles and hanging up cross beams.

In double bottoms all installations for electrical, EDP, sanitary, air condition technology and information media can be accommodated. An entrance for revision work can take place at any place. By this future-safe system, later changes in the installation are rapidly feasible.

The cavity floor unites the advantages of a conventional flowing line with those of the double bottom and offers within ranges with normal static load, as for example in the administrative or building of offices, an economic alternative. Double bottom with constant surface. The entrance to the cavity is made by inspection doors. Nearly all conventional upper linings can be processed by the closed surface, up to the natural stone mosaic problem-free.

The mother boards, from different materials and closed surface also freely selectable upper linings

The sub-construction, consists of galvanized steel columns of different lengths, is adjustable and locking in the height. For the carrying capacity reinforcement or reinforcement there are additionally so-called "C" of profiles and hanging up cross beams.

In cavity floors all installations for electrical, EDP, sanitary, air condition technology and information media can be accommodated. An entrance for revision work can take place only at certain places (inspection doors). By this future-safe system, later changes in the installation are rapidly feasible.

Detailed one

High-strength mineral base plates interlink by special tooth milling of the edges and train so an optically jointless surface. The soils are immediately accessibly and loadable despite their small dead weight extremely. Thus all advantages cavity floor are reached, however without building dampness and drying times. Floor and more takes up electrical and EDP installations, makes climatictechnical functions possible such as heating, ventilation or cooling

Ranges of application:

Office and construction area, industrie and werkraeume, training course and research area, projects with short construction period (drainage times)

Detailed one

The pure space soils depending upon requirements with different electrical bleeders one implements. The mother board consists of a welded tubing frame construction with powder-coated surface. These soils must ensure the high conditions concerning load-carrying capacity, ventilation and electrostatics. For air conditioning steel plates can be perforated. The pure space soil is characterised by an optimal removal of the contaminated room air. Holes in different size make an optical not visible ventilation possible with sourceair-suitable linings.

Pure areas are conceived completely according to your individual requirements and equipped flexibly. The surface lining can exist made of linoleum, PVC, rubber or HPL. In the semiconductor industry large areas with this soil systems are furnished.

Detailed one

Operational areas:

Microelectronics

OI areas

Research

High Tech ranges

Pharmacy and medical technology

Unterhaltungselektronik

Entertainment electronics

The control room soil is a special form of the double bottom. This floor system consists 600 x 600 mm, which are shifted on a bolted sub-construction from carrier profiles and hoehenverstellbaren supports of individual double bottom plates in the standard raster. The switchgear cabinets are placed directly on the girder construction and can thus directly from down be fed. Within the switchgear cabinet range basic frames are integrated after the dimensions. The sub-construction for switchgear cabinet frameworks of C-sections are made. The fields within the cabinet surfaces remain to the free wiring.

The control room sub-construction is free standing, it ensures full stability also without shifted double bottom plates. As base plates both timber material plates, and fiber-reinforced mineral material plates are used.

Operational areas:

Highly -, central and low-voltage areas

in areas for switchgears

Battery plants

Emergency power generators

as special design for complicated bypasses

with stacker enterprise

Special soils are particularly conceived and manufactured, abgepasst and installed after the desires and conceptions of the customer. Flexibility is nowadays in the object area more importantly ever and contributes in such a way to the long-term worth stop of a building. Special soils e.g. assigned in: EDP areas and switching centers, industrie and werkraeume, training course and research areas, office and construction ranges, cinema halls , plenary assembly halls.

The combination of under-floor heating and double bottom:

Already in earlier time the Romans appreciated under-floor heatings in your hot springs - both features do not stand today for no more separately next to each other. By the integration of a copper register into our double bottom plates this combination in perfection succeeds. Herausnehmbare thermal plates with flexible plastic lines ensure the flexibility.

Predivide a climatic double bottom:

invisible shifting of the installation

Flexibility double bottom remains

Gestalltungsfreiheit by omission of heating elements

Adjustment to thermal needs

Efficiency and ecology

Heating and cooling

Floor mat according to desire
